Get to know our products

With our solution, you get control of your pasture
and herd of animals at anytime from anywhere.

Our products

Storfeklave 2

Cattle collar

A robust Nofence collar developed for cattle.

or
Småfeklave 2

Sheep / Goat collar

A robust Nofence collar developed for sheep and goats.

+
The Nofence app

The Nofence app

Create and adjust the virtual fences in the Nofence-app. The app is available on both iOS and Android.

Cattle Charger

Cattle Charger

Cattle Battery

Cattle Battery

Battery for sheep and goat collars

Sheep / Goat Battery

Charger for sheep and goat batteries

Sheep / Goat Charger

Beacon

Beacon

The Nofence collars

Solar cells

A tough, durable collar with solar panels on both sides. Surface scratches will not have a noticeable impact on the effect.


Bluetooth

Four important functions - capture signals from shelter beacons, deactivation of GPS when the animals are in shelter, locating a collar if you have no cell phone coverage and removing a collar from pasture without a mobile signal.

Rechargeable battery

In the grazing season, the batteries are charged by the solar panels. The batteries will last longer if you have large pastures, good mobile coverage and good sun conditions.

Nofence collars

Motion sensor

Registers acceleration along three axes, and is used to both save energy and is the basis for further development to provide valuable information about the animal's condition.

GPS receiver

Nofence uses satellite signals from American and Russian GLONASS to determine its position.


Communication over mobile network

Nofence uses the 2G and 4G network in order to communicate with the app. In order to create pastures, move boundaries and receive notifications, there must be cell phone coverage in the pasture.

Technical details - Cattle collar

Electrical Specification
Input voltage: 3,4V - 4,2V
Power consumption: 500uA to 1,5A
Audio warning level: 82dB @1m
Solar charging max peak power: 2291mW

Communication interface
Bluetooth
LTE Cat-M1 and 2G
GNSS Receiver - Glonass and GPS

Environmental
Ingress Protection: IP67 (@ 0,25m depth in 0,5 hrs)
Temperature range: -25 to +65℃ (Operating and storage)

Physical
Dimension (box): 153,5 x 145,4 x 54,2 mm
Weight collar unit 858g
Weight battery 450g
Weight neck strap 138g
Total weight, carried by animal: 1446g

Electrical Specification
Battery type: Lithium Ion
Rated capacity: 20,1Ah Typ
Watt hour rating: 72,36Wh
Nom Voltage: 3,6V
Max Charge Voltage: 4.2V
Discharge cut off: 2,5V
Built-in protection: Over-charge/-discharge, Over current, Short circuit

Environmental
Ingress Protection: IP67 (@ 0,25m depth in 0,5 hrs)
Temperature range:
- Charge: 0 to +45°C
- Discharge: -10 to +60°C
- Storage:
● 0°C ~45°C, ≤3 month
● 0°C ~23°C, ≤1 year
● Humidity: 40~80%RH, SOC: 45%~55%

Physical
Dimensions: 119,6 x 95,3 x 29,8mm
Weight: 450g
Environment and Safety
This battery meets the requirements of Battery Directives, and the battery parts are RoHS
Compliant.

Standards
This battery meets the requirement of UNITED NATIONS” Recommendations on the Transport of dangerous goods,
Manual of test and criteria ST/SG/AC.10/11/Rev.6, amend1, section 38.3.

Technical Specification
Input Voltage: 90-264VAC
Line freq: 47-63Hz
Max charge current: 2,0A
Max charge voltage: 4,2V
Max output power: 8,4W
Temperature range:
● Operating: 0°C to +40°C
● Storage: -25 to +85°C
Built-in protection: Reverse polarity and short circuit

Package
Docking size: LxWxD 139,0 x 63,2 x 33,0mm
Cable length: 1,8m
Weight complet unit: 373g
Cable plug type: According to country specifications

Approvals
● Medically certified
● Safety: EN 60601-1 ed. 3.1 and EN 60601-1-11
● EMC: EN 60601-1-2 ed. 4
● UL approved

Technical details - Sheep & Goat collar

Electrical Specification
Input voltage: 3,4V - 4,2V
Power consumption: 500uA to 1,5A
Audio warning level: 82dB @1m
Solar charging max peak power: 1385,3mW

Communication interface
Bluetooth
LTE Cat-M1 and 2G
GNSS Receiver - Glonass and GPS

Environmental
Ingress Protection: IP67 (@ 0,25m depth in 0,5 hrs)
Temperature range: -25 to +65℃ (Operating and storage)

Physical
Dimension (box): 84,8 x 90,5 x 109,0 mm
Weight collar unit 292g
Weight battery 192g
Weight neck strap 21g
Total weight, carried by animal: 505g

Technical Specification
Input Voltage: 90-264VAC
Line freq: 47-63hz
Max charge current: 1,5A
Max charge voltage: 4,2V
Max output power: 6,3W
Temperature range:
● Operating: 0℃ to +40℃
● Storage: -25 to +85℃’
Built-in protection: Reverse polarity and short circuit

Package
Docking size: LxWxD 102,7 x 90,0 x 42,5 mm
Cable length: 1,8 m
Weight complete unit: 333g
Cable plug type: According to country specifications

Approvals
● Medically certified
● Safety: EN 60601-1 ed. 3.1 and EN 60601-1-11
● EMC: EN 60601-1-2 ed. 4
● UL approved

Electrical Specification
Battery type: Lithium Ion
Rated capacity: 10,05Ah Typ
Watt hour rating: 36,18Wh
Nom Voltage: 3,6V
Max Charge Voltage: 4.2V
Discharge cut off: 2,5V
Built-in protection: Over-charge/-discharge, Over current, Short circuit

Environmental

Ingress Protection: IP67 (@ 0,25m depth in 0,5 hrs)
Temperature range:
- Charge: 0 to +45℃
- Discharge: -10 to +60℃
- Storage:
● 0℃ ~45℃, ≤3 month
● 0℃ ~23℃, ≤1 year
● Humidity: 40~80%RH, SOC: 45%~55%

Physical

Dimensions: 77,6 x 76,5 x 37,7 mm
Weight: 192g

Environment and Safety
This battery meets the requirements of Battery Directives, and the battery parts are RoHS Compliant.

Sheep with collar
Goat with collar
Cow with collar
